Dental Furnace
High-Temperature Dental Furnace LYL-20DKL
DESCRIPTION:
- Model No: LYL-20DKL
- Heating Rate: ≤0.1-40°C/min
- Rated Voltage: 220V/380V
- Chamber Size: Customizable
- Design Temperature: 800°C-1800°C
- Temperature Control Accuracy: ±1°C
- Temperature Measuring Element: K (0-1300°C) / S(0-1600°C)/ B (0-1820°C)
//
PRODUCT INTRODUCTION
Brief Introduction
The High-Temperature Dental Furnace LYL-20DKL is a new generation of energy-saving and environmentally friendly electric furnace developed through in-house R&D, incorporating advanced technology. The equipment features a modern, aesthetically pleasing design, a sophisticated and rational structure, and is simple and convenient to operate. The exterior casing is crafted from high-quality cold-rolled steel plate, processed with advanced CNC machine tools, and finished with a premium, durable two-tone imported epoxy powder electrostatic spray coating, providing resistance to high temperatures, corrosion, and permanent color retention.
The furnace offers a uniform temperature field, a double-layer insulated furnace body that keeps the surface temperature close to ambient, and adjustable heating rates. The furnace chamber is constructed from imported high-temperature composite fiber materials using a CNC process, ensuring excellent thermal shock resistance, tolerance to rapid heating and cooling, corrosion resistance, and is resistant to sagging, crystallization, and dusting, with no pollution and a long service life.
The control system utilizes microcomputer-based intelligent regulation technology, featuring PID adjustment, full automatic control, and auto-tuning functions. It supports multi-segment program programming, allowing for the creation of various heating, holding, and cooling profiles, achieving high temperature control precision, excellent energy efficiency, and high stability.
The protection system includes independent safeguards against: over-temperature, over-voltage, over-current, thermocouple break, power failure, leakage, and short circuit.
Furthermore, through our self-developed control software, the furnace can be connected to a computer, enabling remote control (start/stop), program setting, program storage, historical curve viewing, and printing for a single furnace or multiple units.
Application
This equipment is primarily used for the processing and fabrication of dental porcelain powders. The furnace employs heating from all sides, resulting in a more uniform temperature field compared to traditional muffle or crystallization furnaces. The sintered dental crowns exhibit better transparency and consistency. The more user-friendly bottom-loading mode provides convenient loading and unloading of materials. It is an ideal choice for dental laboratories.
Qualification & Honor
-
ISO 9001:2015 Quality Management System Certification
-
CE Certification (EU Conformity)
-
Luoyang City "Model Enterprise for Civilized and Honest Operation"
-
"Leading Brand in China's Electric Furnace Industry"
-
"AAA Enterprise for Quality, Service, and Creditworthiness"
-
Products can withstand testing by authoritative inspection institutions; third-party verification certificates can be provided upon request.
Main Functions & Features
-
Energy-saving and environmentally friendly (Furnace chamber uses high-purity composite alumina/ceramic polycrystalline fiber; lightweight, low thermal mass, energy-efficient, operates on average at half power).
-
Easy replacement, saves time and energy (Heating elements are high-quality resistance wires/silicon carbide rods/molybdenum disilicide rods, with long service life and easy replacement).
-
Touchscreen control, convenient and flexible.
-
High temperature control precision (High-quality controller, precision ±1°C). The controller can be accompanied by a third-party test certificate.
-
Good furnace temperature uniformity, heated from all sides (Rational layout, balanced temperature field, no dead zones in chamber).
-
Microcomputer program temperature control, adjustable heating rate, automatic operation requiring no supervision.
-
Automatic protection and alarm for over-temperature, over-voltage, over-current, leakage, thermocouple break, and heater breakage.
-
Electric lift for furnace bottom, smooth and vibration-free lifting, bottom-side material feeding.
-
Application Range: Primarily used for processing dental porcelain powders; an ideal choice for dental laboratories.
-
Double-layer shell with air convection insulation.
-
Powder-coated casing, elegant two-tone appearance.
-
Excellent reputation, numerous satisfied customers.
-
Excellent cost-performance, comprehensive after-sales service, 1-year warranty, lifetime on-site maintenance service.
//
PRODUCT PARAMETERS
Main Technical Parameters
Item |
Specification |
|---|---|
Rated Voltage |
380V 50/60Hz |
Design Temperature |
800℃, 1000℃, 1200℃, 1400℃, 1600℃, 1700℃, 1800℃ |
Heating Rate |
≤0.1–40℃/min (adjustable) |
Heating Element |
High - quality imported resistance wire / High - quality U - type silicon carbide rod / High - quality U - type molybdenum disilicide rod |
Temperature Control Accuracy |
±1℃ |
Temperature Control Mode |
Touch - screen PLC microcomputer control, PID regulation, intelligent microcomputer control, multi - segment programmable temperature control curve, no need to watch (automatic heating, holding, power off when door opens) |
Temperature Measuring Element |
K (0–1300℃) / S (0–1600℃) / B (0–1820℃) |
Furnace Chamber Material |
Ceramic polycrystalline fiber / Alumina fiber / Composite alumina fiber / High - purity composite alumina fiber / Imported fiber |
Furnace Door Structure |
The furnace door serves as the charging table; the bottom is automatically lifted, with stable lifting and no vibration, facilitating loading and unloading |
Heat Dissipation Mode |
Double - layer shell, air insulation layer |
Surface Temperature Rise |
≤30℃ |
Accessories as per model |
2 heating rods, 2 rod tools, 1 crucible tong, 1 pair of refractory gloves, 1 bag of zirconia beads, 1 crucible, 1 copy of instruction manual and certificate of conformity |
Selection Guide
Model |
Chamber Diameter (mm) |
Chamber Height (mm) |
Power Supply Voltage (V) |
Power (KW) |
Temperature Control Accuracy |
LYL-20DKL-1 |
100 |
100 |
220 |
2 |
±1℃ |
LYL-20DKL-2 |
120 |
120 |
220 |
2.5 |
±1℃ |
Temperature Range |
800°C - 1800°C, selectable. |
||||
Customization |
Non-standard experimental furnaces of different sizes can be custom-made based on customer requirements. |
||||
//
STANDARD ACCESSORIES
Standard Accessories
Name |
Picture |
Quantity |
Description |
|
High-temperature Gloves |
|
1 pair |
Excellent comfort, keeps hands warm; Cut-resistant, abrasion-resistant, and heat-resistant (withstands contact with 350°C heat for 60 seconds, 100°C heat for 180 seconds). Durable. |
|
|
Heating Elements |
Silicon Carbide Rods |
|
2 pieces |
Silicon carbide elements, characterized by their high operating temperature, hardness, and brittleness, are ready for use after formation. For instance, silicon carbide rods and tubes, made from silicon carbide, can achieve a heating temperature of up to 1500°C under dry air conditions. Under vacuum conditions, the operating temperature ranges from 1000°C to 1200°C, while in a nitrogen atmosphere, the long-term use temperature reaches 1350°C. |
Silicon Molybdenum Rods |
|
2 pieces |
Silicon molybdenum rods, when heated to high temperatures in an oxidizing atmosphere, form a dense layer of quartz glass on the surface, protecting them from further oxidation. Therefore, silicon molybdenum rods exhibit high-temperature oxidation resistance. In an oxidizing atmosphere, they can reach temperatures up to 1800°C, making them suitable as heating elements for high-temperature furnaces in industries such as electronics, ceramics, magnetic materials, glass, metallurgy, and refractories. |
|
Crucible Tongs |
|
1 piece |
1.A common chemical instrument typically used for handling crucibles. Generally made of stainless steel or other non-flammable, oxidation-resistant hard materials. 2.Clean crucible tongs must be used. 3.When using crucible tongs to pick up a hot crucible, the tips should be preheated first to prevent the crucible from cracking due to localized cooling. After use, the tongs should be placed on a table or asbestos mat with the tips facing upward. 4.After the experiment, crucible tongs should be cleaned, dried, and stored in the laboratory equipment cabinet. 5.Use the curved section for gripping crucibles; the tips are for other purposes. 6.Crucible tongs are not necessarily used exclusively with crucibles; they can also be used independently. |
|
Optional Accessories List
Observation Window |
Exhaust Hole & Chimney |
Vacuum & Atmosphere |
Crucible |
Zirconia Beads |
Furnace Floor Plate |
Air Blowing |
Thermocouple |
Caster Wheel |
Special Note
Item |
Content |
|---|---|
|
Factory Environment |
1. Indoor use; 2. Ambient temperature range: ±5~45℃; 3. Relative humidity of surrounding environment does not exceed 85%; 4. No conductive dust, explosive gases, or gases that can severely damage metals and insulating materials around the furnace. |
|
Safety Protection |
1. When using the electric furnace for the first time or after long-term shutdown, baking is required; otherwise, it is easy to cause furnace cracking. 2. Keep clean regularly and check whether the furnace wiring is in good contact. 3. When using the electric furnace, the furnace temperature shall not exceed the rated temperature to avoid damaging the heating elements. It is forbidden to pour various flammable liquids and molten metals into the furnace. 4. During operation, generally below 300℃, the heating rate should not be too fast, because the furnace chamber is cold at the beginning of heating and needs to absorb a lot of heat. |
|
Friendly Tips |
1. To ensure the normal service life of the equipment, please do not run at the rated temperature for a long time. 2. Carefully check and verify the quantity of goods and accessories upon receipt to avoid inconvenience caused by missing or incorrect items. 3. To extend the service life of the instrument, we recommend a heating rate and cooling rate of 10℃/min. 4. The cooling rate should not exceed 5℃/min. 5. This furnace has no vacuum sealing structure, so flammable and explosive gases must not be introduced. 6. After this furnace has been used for a period of time, slight cracks may appear in the furnace chamber, which is a normal phenomenon and will not affect usage. At the same time, it can be repaired with alumina coating. |
Common Faults & Trouble Shooting
Fault Phenomena |
Fault Causes |
Troubleshooting Methods |
No power indication when turning on the control power switch |
Control circuit issue, blown fuse, or no power supply |
Check for short circuits, rectify, and replace the fuse |
Voltage present but no current during equipment operation |
Heating element broken |
Replace the heating element |
Instrument PV display shows the maximum temperature for the corresponding thermocouple type |
Thermocouple short circuit |
Replace the thermocouple |
All power supplies normal but furnace does not heat up |
Main control circuit damaged |
Notify a qualified technician for repair |
//
